Chenbro RM42200 4U Rackmount Chassis

Features & Benefits

• Supports M/B up to 12” x 10.5”
• Optional 15-slot rear window for industry backplane
• Available for rackmount and stand-alone installation
• Rotatable 5.25” cage to keep device in horizontal position
• Dedicated front 120mm fan for add-on card cooling
• Card retainer to hold low profile and full height add-on cards
• User friendly design on front key lock and lifting handle (stand-alone)
• Supports PS/2 single or mini-redundant PSU

Specifications

Technical Details
Case Form Factor	4U Rackmount
Motherboard Compatibility	Mini-ITX, Micro ATX, Standard ATX (12" x 10.5")
Drive Bays	External 5.25"	3
	External 3.5"	2
	Internal 3.5"	3
	Internal 2.5"	0
	Hotswap 3.5"	0
	Hotswap 2.5"	0
	Slim Optical	0
	Slim FDD	0
Hot-Swap Backplane	Not Applicable
Expansion Slots	Full Height	7
	Low Profile	0
Cooling	1x Front Mounted 120mm PWM Included 2x Rear Mounted 80mm Optional
Power Supply Form Factor	Standard ATX or 4U Mini Redundant
Front Panel Connectors, Switches & Indicators	Power Switch	YES
	Reset Switch	YES
	USB 2.0	2
	USB 3.0	0
	Serial	0
	Indicators	Power, LAN, and HDD LEDs
Colour	Silver
Material	SGCC
Dimensions & Weights
Packaging	Single Box
Dimensions	522 x 430 x 176 (mm), 20.5” x 16.9” x 6.9”
Weight	13.4kg (Approx)
What's Included
1 x Chassis 1 x Accessory Box
